Descrizione prodotto
Features
- Large custom made toroidal transformer and smoothing capacitors for power supply
- Option to fit a MC or MM phono module
- All discrete transistor audio stages
- Multiple stages of power supply regulation
- High quality all aluminium case work
- Three year guarantee
- Available in black or titanium
Specifications
-
- Input Impedance : MC adjustable from 100 Ohms to 1,500 Ohms by jumper link. MM 47K Ohms
- Sensitivity : MC 250uV in for 250mV out at 1KHz (adjustable by jumper link). MM 2.5mV in for 250mV out at 1KHz
- Frequency Response : +/-0.25dB from 30Hz to 20KHz, ref. 1KHz, with low frequency roll off below 30Hz
- Total Harmonic Distortion : <0.01% at 1KHz
- Power Consumption : <25VA
- Mains Supply : 110/120V or 220/240V, 50/60Hz (factory set)
- Dimensions – H x W x D : 90mm x 440mm x 300mm
- Nett Weight (unpacked) : 7kg
- Gross Weight (packed) : 9kg
