Descrizione prodotto

• Digital to analogue convertersDual Wolfson WM8740 24-bit DACs
• Digital filterAnalog Devices ADSP21261 DSP; upsampling to 24-bit/384kHz
• Analogue filter2-Pole Dual Differential Bessel Double Virtual Earth Balanced
• Frequency response20Hz to 20kHz (±0.1dB)*
• THD @ 1Khz 0dBFs<0.001% 24-bit
• THD @ 1kHz -10dBFs<0.001%
• THD @ 20kHz 0dBFs<0.002%
• Signal to Noise Ratio-112dBr
• Total correlated jitter<130pS
• Crosstalk @ 1kHz< -130dB
• Crosstalk @ 20kHz< -112dB
• Output impedance<50 Ohms
• Max. output level (unbalanced)2.1V rms
• Max. output level (balanced)4.2V rms (2.1V per phase)
• Digital input word widths supported16-24bit
• Digital input sampling frequencies supported32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz**, 192kHz
• Audio output upsamplingFixed 24-bit/384kHz
• Max power consumption12W
• ColourBlack or silver
• Dimensions (HxWxD)52 x 215 x 191mm; (2.0 x 8.6 x 7.6”)
• Weight1.2kg/2.6lbs
• *Steep filter disabled
• **Digital 1 & 2 Inputs only
• Headphone output
• THDat 1kHz 0dBFS 24-bit signal with 22kHz low pass filter = 0.001%
  at 20khz 0dBFS 24-bit signal with 80kHz low pass filter = 0.003%
• S/N-111dBrA
• Frequency response10Hz – 100kHz
• Recommend headphone impedance 32 Ohm to 600 Ohm.
