Descrizione prodotto

• D/A convertersTwin Analog Devices AD1955 24-bit DACs
• Digital filter2nd Generation ATF2 up-sampling to 24-bit/384kHz. Linear Phase, Minimum phase or Steep modes.
• Analogue filter2-pole differential Bessel with DC servo (for both XLR and RCA outputs)
• Digital audio inputs1 x AES/EBU, 2 x S/PDIF coaxial and 2 x TOSLINK optical
• USB Audio inputUSB Type B conforms to USB Audio profile 1.0 or 2.0 (user selectable)
• Analogue audio outputsBalanced XLR and unbalanced RCA analogue audio outputs
• CompatibilityUPnP: Linear PCM 16-24 bit, 11.025-192kHz
  Local USB media:Linear PCM 16-24 bit, 11.025-192kHz USB Audio1.0: Linear PCM 16-24 bit, 44.1-96kHz USB Audio 2.0: Linear PCM 16-24 bit, 44.1-192kHz or DSD x64 (DSD also available over UPnP streaming)
• TOSLINK: 16-24 bit, 32-192kHz (using high quality TOSLINK optical cable) S/PDIF: Linear PCM 16-24 bit, 32-192kHz AES3/EBU: Linear PCM 16-24 bit, 32-192kHz BT100 Bluetooth receiver: A2DP plus aptX Internet radio: 16-24 bit, 11.025-192kHz
• Audio formatsALAC, WAV, FLAC, AIFF, DSD (x64), WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis
• Standby power consumption<0.5W
• Dimensions
  (H x W x D)115 x 430 x 360mm (4.5 x 16.9 x 14.7”)
• Weight8.1kg (17.9lbs)
